Aeromotive

Aeromotive Eliminator In-Tank Fuel Pump Module Brushless w/Pickup/Speed Controller 18044

PART NUMBER:
18044
MPN:
18044
Availability:
Ships from Manufacturer ( 2-3 Week Lead Time )
Shipping:
FREE OVER $98 IN US 48
Type:
In-Tank Fuel Pumps
Inlet Fitting:
0.75″ Pickup Tube
Outlet Fitting:
ORB‑10 Female
Race Fuel Compatible:
Yes
e85 Compatible:
Yes
  • Aeromotive Eliminator In-Tank Fuel Pump Module Brushless w/Pickup/Speed Controller 18044
  • Aeromotive Eliminator In-Tank Fuel Pump Module Brushless w/Pickup/Speed Controller 18044
  • Aeromotive Eliminator In-Tank Fuel Pump Module Brushless w/Pickup/Speed Controller 18044
  • Aeromotive Eliminator In-Tank Fuel Pump Module Brushless w/Pickup/Speed Controller 18044
$1,524.45

Description

Aeromotive Eliminator In-Tank Fuel Pump Module Brushless w/Pickup/Speed Controller 18044

P/N 18044: Brushless Eliminator Fuel Pump Module with Fuel Cell Pickup and Variable Speed Controller
Designed as a direct drop-in replacement for the any Aeromotive Stealth Fuel Cell, including COPO, Cobra Jet or Drag Pak race cars. This configuration is also a great option when building a 10″ deep custom fuel cell.
The Eliminator performance you expect and more:

  • Fuel Injected Engines: GAS
    up to 1900 FWHP – naturally aspirated
    up to 1400 FWHP – forced air induction
  • Carbureted Engines: GAS
    up to 2300 FWHP – naturally aspirated
    up to 1700 FWHP – forced air induction
  • Fuel Injected Engines: E85
    up to 1330 FWHP – naturally aspirated
    up to 980 FWHP – forced air induction
  • Carbureted Engines: E85
    up to 1610 FWHP – naturally aspirated
    up to 1190 FWHP – forced air induction
  • E85 Compatible, reduce max FWHP by 30%
  • Lighter than the traditional Eliminator pump.
  • Reduced current draw at higher, EFI pressures.
  • Extended service life in methanol and ethanol.
  • Integral, external brushless controller for clean installation, cooler fuel and enhanced reliability.
  • Quieter than the traditional Eliminator Pump.
  • ORB-10 outlet port.
  • Requires straight 12-VDC to 16-VDC power supply.
  • Aeromotive Brushless pumps are not designed for use with 16v charging systems, typically operating in the 16-18v range.  If you are running a 16v charging system, the use of a voltage regulator or step down to typical 12v charging system voltages will be necessary.
  • Not compatible with pulse modulated systems or fuel pump speed controllers.
  • This product is not legal for sale or use on emission-controlled vehicles except when used as a direct replacement part matching OEM specifications

Aeromotive’s True Variable Speed Controller offers the advantages of built-in pump speed control via a dedicated 0-5V analog DC input signal. The Controller capitalizes on our existing brushless technology by reducing fuel flow during low engine demand and decreasing an already low current draw, therefore minimizing both motor heat the introduction of environmental via reduced fuel recycling.
EFI Rated flow of 1,000 lbs./hr. @ 45 psi, 13.5 volts
Carb Rated Flow of 1,300 lbs./hr. @ 9 psi, 13.5 volts

Specifications

Series Eliminator
Maximum Flow Rating 1250
Fuel Type Gas/E85
Universal Or Specific Fit Universal
Internal Or External Internal
Pump Design Rotary Vane
Motor Style Brushless
Integrated Controller Yes
Pulse Width Modulation Compatible No
Fuel Delivery Type Carburation & Fuel Injection
Inlet Outside Diameter 0.75
Outlet Type Female Thread
Outlet Outside Diameter ORB-10
Voltage 12
Negative Ground Yes
Wire Quantity 3
Wiring Harness Included No
Terminal Quantity 0
Terminal Type Lead Wire
Strainer Included Yes
Fuel Sending Unit Included No
Regulator Included No
Mounting Bracket Included Yes
Mounting Hardware Included No
Seal And Lock Ring Included Yes
Gasket Or Seal Included Yes
Grade Type Performance
